Worm gear is the core drive component in screw jacks. A worm gear for screw jacks typically consists of a hardened worm shaft meshing with a bronze worm wheel. It provides high reduction ratios within a compact space, enabling small motors to handle heavy loads. In industrial settings, screw jacks equipped with worm gears are widely used for lifting, lowering, or positioning heavy loads with precision. A key advantage of the screw jacks worm gear system is self-locking, which is critical for vertical lifting safety. Screw jacks equipped with worm gears operate smoothly and quietly, with low vibration, widely used in material handling, construction, and automation industry.
Screw Jacks Worm Gear
Specification
Module
1.8
Application
Screw Jack
Material
CuSn12Ni2+42CrMo4
Heat Treatment
NA+Nitriding
Accuracy
DIN8+DIN6
Worm Gear Used In Screw Jacks
We have been manufacturing worm gears for many years, from start to finish including inspection, we have full in-house control, which allows us to control every step that matters and maintain strict quality standards and more controllable delivery time.
As the driving component, the worm shaft is mainly subjected to continuous force and wear, so it requires high strength and surface hardness. This worm shafts are made by 42CrMo4, which offers excellent toughness and fatigue after heat treatment. And worm shaft grinding is needed to reduce transmission noise, improve transmission efficiency, and extend service life.
The worm wheel begins with casting in-house, so we can control material consistency and blank quality. After casting is complete, we move to machining and then hobbing the teeth. During the hobbing process, we will mesh the worm wheel with its matched worm shaft to check backlash, and adjust the worm wheel based on the measurement data, until the worm gear set achieves the ideal meshing condition.
Before every shipment, we will conduct a full inspection for the worm gear set and prepare full set of quality report for customer’s approval, including dimension report, material cert, heat treatment report, accuracy report, meshing test etc. Only when it’s all approved by our customers, we will send out the parts.
With decades of experience, we deliver reliable, high performance worm gear set tailored to customer needs and demaning applications.
